Motorised Vibratory Conveyor
Robust, maintenance-free bulk conveying for any continuous process. Twin unbalanced motors drive a mild-steel or stainless tray on coil springs — moving material up to 600 tons/hour with controlled, vibration-isolated flow.
Overview
Controlled bulk conveying, isolated from the floor
The motorized vibratory conveyor consists of a horizontal tray made of mild steel or stainless steel, fixed to the frame. Vibration is provided by two special unbalance motors fixed on either side of the tray, and the complete tray-and-motor assembly rests on a set of coil springs so no vibration is transmitted to the stand or the ground. As the motors start, vibration sets the material in motion — and controlling the vibration gives controlled flow. The motor housing is a totally enclosed design. These feeders are robust, maintenance-free and highly durable, delivering high-throughput feed at higher amplitudes, with flexible custom designs to meet product-specific demands.
Features & benefits
Robust, durable, configurable
High throughput
Max design capacity up to 600 tons/hour at conveying speeds up to 30 metres/minute.
Twin unbalance motors
Two motors on either side of the tray, with a totally enclosed housing design.
Custom trough designs
Pan tray, ‘V’ tray, scarf tray and tubular trough to suit the material.
Wear-resistant liners
Liner options including C45, Sail Hard, Hardox and polymer for abrasive duties.
Vibration isolated
Coiled springs, oscillation mounts or rubber marshmallows keep vibration off the floor.
Hygienic & hazardous options
GMP sanitary designs, clean-in-place accessories, quick-release dust covers and special designs for hazardous environments.
Specifications
Configurable to your duty
| Parameter | Specification |
|---|---|
| Max design capacity | Up to 600 Tons/Hour |
| High conveying speeds | Up to 30 Metres/Minute |
| Max conveying length | Up to 12 Metres |
| Custom trough designs | Pan Tray, ‘V’ Tray, Scarf Tray, Tubular Trough |
| Liner options | C-45 grade, Sail Hard, Hardox, SS 202, Salima, HDPE, ceramic, polymer etc. |
| Drive type | Vibrator Motors, CE & ATEX certified |
| Isolation types | Coiled Springs, Oscillation Mounts & Rubber Marshmallows |
| Mounting type | Base Mounted or Suspension Mounted |
| Optional upgrades | Hygienic Sanitary GMP Designs, Clean-In-Place Accessories, Special Designs for Hazardous Environments, Quick-Release Dust Covers |
Need precise dosing rather than conveying? This conveyor runs on twin unbalance motors for continuous transport. For instantly controllable feed rates and gram-level dosing, see the electromagnetic vibrating feeder.
Applications
For any continuous process industry
Related equipment
Often specified alongside this
Vibratory Spiral Elevator
A motorized vertical spiral conveyor consisting of mild-steel spiral trays and a main…
View product
Vibrating Table
Electromagnetic vibrating table consisting of a solid base plate and a vibrating top
View product
Vibrator Motor
Premium unbalanced industrial vibrator motors from 0.04 kW to 10 kW with centrifugal…
View productFAQs
Motorised Vibratory Conveyor — common questions
How does the motorized vibratory conveyor work?
What capacity and length can it handle?
Can it be built for abrasive or hazardous materials?
How is it mounted and isolated?
Request a Motorised Vibratory Conveyor quote
Tell us your material, throughput, conveying length and trough preference and we’ll configure the conveyor and quote it delivered to South Africa.
