Vibrator Motor

Premium unbalanced industrial vibrator motors from 0.04 kW to 10 kW, with centrifugal force up to 130,000 N in 2, 4, 6 and 8-pole designs. CE-certified, ATEX-approved and IP66-rated — the dependable drive behind screens, feeders, conveyors and flow aids across South African plants.

0.04–10 kW Up to 130,000 N CE · ATEX · IP66

Request a quote WhatsApp us

Overview

The reliable drive on every vibrating machine

As a leading manufacturer of external electric vibrators, Saideep vibrator motors serve as ideal drives for flow aids, vibrating screens (dewatering, dry and high-frequency), grizzly feeders, vibrating pan feeders, vibratory knock-out machines, furnace chargers, vibrating tables and spiral elevators.

Vibrator motors — also called vibrating motors — provide the controlled vibration that conveys, screens, sizes and compacts material across mining, quarrying, food, cement and chemical operations. Built for continuous duty in the harshest conditions, they are exported and supported throughout South Africa.

Technical specifications

Vibrator Motor at a glance

Power rating	0.04 kW – 10 kW
Centrifugal force	Up to 130,000 N
Poles	2, 4, 6 & 8 pole
Supply	Single phase & three phase; voltages to client requirement
Duty	Continuous (S1) & periodic (S4)
Enclosure	IP66, weather- and dust-proof
Insulation	H-Class winding (high-temperature)
Bearings	SKF ball bearings · NSK (Japan) roller bearings
Castings	Aluminium Special Grade (small) · SG Iron (large)
Series	Standard · Flameproof (Explosion-proof) · Milling · High Frequency
Mounting	Flange & centre-flange · wedge · foot mounted
Certifications	CE · ATEX (Zone 1 & 2 / Zone 21 & 22) · ISO 9001:2015

Specifications vary by model and series. Contact us with your application for an exact selection and data sheet.

Download the catalogues

Vibro Motor catalogue (PDF) Flange-mounted vibrator motor catalogue (PDF) Grain milling series catalogue (PDF)

Features & build quality

Engineered for rigorous, continuous duty

Durable castings — light, maintenance-free Aluminium Special Grade on small motors; high-strength SG-iron on large motors.
H-Class insulated winding — operates reliably at higher temperatures.
Premium bearings — best-in-class SKF ball bearings and NSK Japan roller bearings.
Flexible electricals — single- and three-phase designs for varied voltages or overseas client demand.
Continuous or periodic duty — available as S1 (continuous) and S4 (periodic) duty.

IP66 enclosures — designed for the harshest environments and weather conditions.
Superior paint coatings — trained and supported by Hempel for lasting corrosion protection.
Hazardous-area ready — ATEX-certified for Zone 1 & 2 and Zone 21 & 22.
Unparalleled technical support — expert help with design and motor selection.
Certified quality — ATEX, CE and ISO 9001:2015 across the range.

Series & mounting

Configured for your machine

Saideep manufactures highly versatile electric vibratory motors in Standard, Flameproof (explosion-proof), Milling and High-Frequency series, categorised by mounting configuration.

Flange & centre-flange

Designed for circular vibro screens and sifters, portable/mini vibrating screens and gyratory screens.

Wedge mounted

Used on large gyro (round) screens where high force and rigid mounting are essential.

Foot mounted

Ideal for vibratory & knock-out tables, vibrating and grizzly feeders, destoners, purifiers, linear screens, classifiers, dewatering screens, spiral elevators, conveyors, chutes, bins, hoppers and silos.

Vibrator motor application on vibrating equipment

Applications

Where Saideep vibrator motors work

Flow aids on bins, hoppers, silos & chutes
Dewatering, dry & high-frequency vibrating screens
Grizzly feeders & vibrating pan feeders
Vibratory knock-out machines & furnace chargers
Vibrating tables & vibratory spiral elevators

FAQs

Vibrator Motor — common questions

What power and force range do your vibrator motors cover?

Our unbalanced vibrator motors range from 0.04 kW to 10 kW with centrifugal force up to 130,000 N, available in 2, 4, 6 and 8-pole configurations to match the frequency and amplitude your machine needs.

Are the motors suitable for explosive or hazardous areas?

Yes. A Flameproof (explosion-proof) series is ATEX-certified for Zone 1 & 2 (gas) and Zone 21 & 22 (dust), making them suitable for mining, grain, chemical and other hazardous environments.

Can I get single-phase and special-voltage motors for South Africa?

We supply both single-phase and three-phase motors and can build to South African voltages and frequency or any overseas requirement — just specify your supply when you enquire.

How do I select the right model?

Tell us the machine type, material, required force/amplitude, mounting and duty cycle. Our application engineers will recommend the correct series, pole count and mounting and provide a full data sheet with your quotation.

Request a Vibrator Motor quote

Share your application and supply details and we’ll size the right motor, confirm certification and quote it delivered to South Africa.
